Place of Origin:
China
Brand Name:
HelithTech
Model Number:
Hyper 48200
Contact Us
Video
| Parameter | Value |
|---|---|
| Rack-Mounted Power Bank | Yes |
| Rack-Mounted Power Supply | Yes |
| Rack-Mounted Energy Source | Yes |
| Max Discharge Current | 100A |
| Dimensions | 442x410x133 3U |
| Weight | 42kg |
| Cycle Life | >6000 Cycles |
| Protection Level | IP65 |
| Voltage | 51.2V |
| Charge Voltage | 51.2V |
| Capacity | 100Ah |
| Discharge Cut-off Voltage | 51.2V |
| Warranty | 5 Years |
Q1:What is the expected lifespan of the Hyper 48100 battery?
The Hyper 48100 has a cycle life of more than 6000 cycles, ensuring long-term performance and reliability for commercial and industrial applications.
Q2: Can I install multiple Hyper 48100 units in parallel?
Yes, the Hyper 48100 supports both series and parallel connections, allowing you to scale your energy storage system according to your needs.
Q3: What is the maximum charge/discharge current of this battery?
The maximum charge and discharge current of the Hyper 48100 is 100A, making it suitable for high-demand applications.
Q4: What temperature ranges can the battery operate in?
The battery operates within a charge temperature range of 0°C to 55°C and a discharge temperature range of -20°C to 55°C.
Q5: Does the Hyper 48100 come with a built-in display?
The battery comes with an optional LCD display for real-time monitoring of key parameters such as voltage, current, and charge status.
Q6:What communication interfaces are supported by the Hyper 48100?
The Hyper 48100 supports RS485 and CAN communication interfaces, allowing for seamless integration into energy management systems.
Q7: What type of cells are used in the Hyper 48100?
The battery uses high-quality A-Grade LiFePO4 prismatic cells, ensuring safety, efficiency, and long cycle life.
